产品描述Product description
◆FA7-6A系列是一款专用型的按钮开关，集成防尘功效，内部为快速行动结构，应用于种种手持式电动工具，如：100和125角向磨光机、模具电磨、也可应用于电动园林工具、如：打草机、小型电链锯等。
◆FA7-6A series are special type push-button switch, integrated dustproof, with snap-action structure, for used in portable power-tools such as 100mm and 125mm Angle Grinders, Die Grinders, etc. Also suitable for gardening tools, such as Grass Trimmers, small Electric Chain Saws, etc.
产品特征Features
◆可选带以下附件 Optional with the accessories as follows:
→开关下盖 Switch bottom Cover
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大攻击电流 Max. Inrush current at 250V60A
→最大攻击电流 Max. Inrush current at 125V90A
→接触电阻 Contact re sistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7MOhm
→基本介电强度 Dielectric strength of function1500V
→增强介电强度 Dielectric strength of reinforced3000V
→情况温度 Ambient temperature0°C~55°C
→阻燃品级 FlammabilityUL 94V-0
→防护品级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端 Input side:
→2×接线柱端子 Pillar terminals φ=2.8mm
◆输出端 Output side:
→可选螺钉端子 Optional Screw terminals M3.5/M3.0
→可选接线柱端子 Optional Pillar terminals φ=2.8mm
→可选插片端子 Optional 2.8×0.8mm
电气参数和认证 Electric Rating and Certification
